EPIC1500 AudioControl Monoblock 1500w Amplifier

The AudioControl EPIC Series Amplifier delivers powerful, heart-pounding bass in a compact, thermally efficient design. Perfectly paired with The Epicenter Bass Restoration Processor (sold separately), it enhances your bass experience to new levels. This amplifier offers exceptional sound quality and is the only AudioControl amplifier to include a bass knob for easy control.

Digital Class-D Amplifier: Powerful yet compact and stable down to a 1 ohm load.
0-12dB Variable Bass Boost Q: Selects the frequency to boost
Direct Wire Terminals with Hex Screws: Provide solid, reliable connections.
Large Power and Speaker Terminals: Designed for maximum current flow. 4-Gauge Power and 8-Gauge Speaker
91dB+ Signal-to-Noise Ratio (@ CEA Standard): Ultra-efficient idle draw (< 0.5-1A).
Smart Auto Reset Protection Circuit: Multiple protection modes are in place to prevent damage if your amplifier encounters an issue.
Output Over-Current Protection (OCP)
Input Over-Voltage Protection (OVP)
Input Under-Voltage Protection (UVP)
Output DC-Offset Protection (DCP)
Over-Temperature Protection (OTP)
0-12dB Variable Bass Boost Q: Selects the frequency to boost
THE EPICENTER LINK: Connects to EPIC (Power & Remote) to simplify the installation of The Epicenter

• Compact High-Power Class D Monoblock Amplifier

• High-Current Design – 1Ω Stable

• 1 x 300 Watts @ 4 ohms, Continuous Power (RMS) @ 14.4V

• 1 x 500 Watts @ 2 ohms, Continuous Power (RMS) @ 14.4V

• 1 x 750 Watts @ 1 ohm, Continuous Power (RMS) @ 14.4V

• 1 x 3000 Watts @ 2 ohms Bridged (Strapped), Continuous Power (RMS) @ 14.4V
• Frequency Response (+/- 1 dB): 10 Hz – 190 Hz

• S/N Ratio: 92.8 dBa, Ref 600 Watts @ 4 ohms

• Line-Level Inputs: 500mV – 6V RMS

• Power / Ground Wire Gauge: 4 AWG

• Recommended Fuse Rating: 150 Amps

• Low Pass Filter: 12dB/octave Linkwitz-Riley, 40 Hz to 180 Hz
• Subsonic Filter: 12 dB/octave Linkwitz-Riley, Off to 50 Hz
• EPIC Boost: Frequency Center: 30-80 Hz, Gain: 0 to 12 dB
• Speaker Terminal Wire Gauge: 8 AWG

• Smart Auto-Reset Protection Circuit

• Strapable: Yes

• Epicenter Link: Yes
• IN THE BOX: EPIC1500, Wrench, Screws, ACR-E Remote Level Control and Cable, The Epicenter Link (1m Harness), Manual, Warranty
• DIMENSIONS: 6.1″ W x 10.59″ L x 2.01″ H
