QA4-2000 Quantum Bridgeable 4 Channel Amp 1000W
Out of Stock
$16999
MSRP
MSRP
- QA4-2000
QA4-2000 : 4-Channel Class A/B Amplifier
- 4 Channel Full Range Class AB Circuitry
- 2Ω Stereo load Capability
- Low level RCA inputs
- Variable Crossover: HPF/LPF/Full
- Bridgeable outputs @ 4Ω load
- Compatible with any 4/2Ω Loudspeaker
- High Efficiency Mosfet Design
- Q-Sink Heat Management System
- 4 X 125 Watts @ 4Ω
- 4 x 250 Watts @ 2Ω
- 2 x 500 Watts @ 4Ω (Bridged)
- Bandwidth : 18Hz - 22KHz
- Input Sensitivity: 200Mv – 8V
- Crossover filter slope in Stereo: 12dB
- Channel 1-2 HP filter range: 32 Hz - 2 KHz
- Channel 3-4 HP filter range: 32Hz - 2KHz
- Channel 3-4 LP filter range: 50Hz - 250Hz
- Minimum Load : 2 Ω Stereo / 4Ω bridged
- L = 10.55"/ 268 mm
- W = 7.09"/ 180 mm
- H = 2.24"/ 57 mm
QA4-2000 : 4-Channel Class A/B Amplifier
- 4 Channel Full Range Class AB Circuitry
- 2Ω Stereo load Capability
- Low level RCA inputs
- Variable Crossover: HPF/LPF/Full
- Bridgeable outputs @ 4Ω load
- Compatible with any 4/2Ω Loudspeaker
- High Efficiency Mosfet Design
- Q-Sink Heat Management System
- 4 X 125 Watts @ 4Ω
- 4 x 250 Watts @ 2Ω
- 2 x 500 Watts @ 4Ω (Bridged)
- Bandwidth : 18Hz - 22KHz
- Input Sensitivity: 200Mv – 8V
- Crossover filter slope in Stereo: 12dB
- Channel 1-2 HP filter range: 32 Hz - 2 KHz
- Channel 3-4 HP filter range: 32Hz - 2KHz
- Channel 3-4 LP filter range: 50Hz - 250Hz
- Minimum Load : 2 Ω Stereo / 4Ω bridged
- L = 10.55"/ 268 mm
- W = 7.09"/ 180 mm
- H = 2.24"/ 57 mm
